Xsens Metagloves by Manus



Your Xsens motion capture system just got handier

The Xsens Metagloves by Manus uses high-fidelity finger tracking using sub-millimeter accurate fingertip tracking sensors and can be seamlessly added to your Xsens mocap system.

Buy now

Add finger tracking directly into Xsens Motion Capture Software

Hardware and software go hand in hand. The Xsens Metagloves by Manus are fully integrated into Xsens’ Motion capture software, allowing you to deliver real-time finger data into your existing pipeline. They are free of drift and deliver highly accurate and reliable finger capture data.

The gloves are immune to magnetic interference, similar to Xsens’ motion capture solutions, giving you full flexibility to capture anywhere. Finger tracking can be added to all Xsens motion capture hardware and software.

Request more information



Xsens Metagloves by Manus 510
Xsens Metagloves by Manus 217

Stream combined data to a single source

Stream Xsens Metagloves finger data together with the Xsens body data as a single source into your animation pipeline. The Manus' Quantum technology creates an accurate hand skeleton by automatically calibrating your hand size. It then sends the finger data to your Xsens software, creating an accurate digital copy of your hand that can mimic even the most complex movements and poses.

Buy now

Hardware

Xsens Metagloves by Manus 472

Features

The Xsens Metagloves by Manus have the following features:

  • Precise Finger Tracking
    The only glove with absolute, millimeter precise positional tracking in 3D-space, drift free. Not even in fast acceleration/declaration scenarios.
  • Fast and Accurate Calibration
    Complete 3 hand poses in a few seconds for total hand calibration. No need to re-calibrate ever as your calibration is stored in your profile. Multi-user calibration so you and your team can get to work the most efficient way.
  • Xsens Adapters
    Easily mount your Xsens Link or Xsens Awinda sensors on top of the Xsens Metagloves by Manus with the provided adapters.
  • Interchangeable Battery
    Experience up to 4 hours of uninterrupted motion capture time. Batteries of the Xsens Metagloves can be easily swapped no need to recalibrate as your calibration is safely stored. Exchange and continue recording!

Buy now

Attachment methods

You can wear the glove sensors on the fingertips in multiple ways. Choose the method that fits your needs best.

Finger Tapes for Metagloves

Finger tapes

Wrap the finger tapes around the fingertips. The glove sensors are attached to the mounting clips on top. This method provides a very steady mounting of the sensors.

Finger Sleeves for Metagloves

Finger sleeves

You can wear the finger sleeves by sliding them over your fingertips. The gloves sensors are attached to the mounting clips on top. This method provides a quicker way to wear the glove sensors. The finger sleeves are available in three sizes.

Software

Software integrations

The Xsens Metagloves by Manus are natively embedded into Xsens Animate software to deliver easy integration into your software pipeline. The finger tracking data is compatible with all major 3D software packages such as:

  • Unreal Engine
  • Unity 3D
  • Autodesk (3DS Max, Maya, MotionBuilder)
  • Houdini
  • Cinema 4D
  • Blender
  • And more

The Xsens Metagloves by Manus is compatible with all Xsens software plug-ins and integrations into third-party software.

MVN Animate - Gloves

Specifications

Xsens Metagloves by Manus 267
Finger sensor type

Absolute position, 3 axis rotation

Signal latency

<5ms

Sensor sample rate

120Hz

Battery duration

4 hours (swappable)

Charge time

2 hour USB-C

Weight

70gr

Wired Communication

USB-C

Wireless Communication

Proprietary HP 2.4 GHz protocol

Wireless range

up to 50 feet (15 meters)

Textile information

One size fits all (washable)

Finger attachments

Finger tapes and finger sleeves

What's in the box



  • 2x Xsens Metagloves
  • 1x Wireless dongle
  • 2x Quantum batteries
  • 2x USB-C cables
  • 1x Set of Xsens adapters (Xsens Link & Xsens Awinda)
  • 36x Finger Sleeves 1/2/3
  • 12x Finger tapes
  • 1x Getting started guide
  • 1x Travel case

Buy now

Xsens Metagloves Packaging & Case Render

Xsens Metagloves by Manus Customer Cases

I have a question

Xsens Animate is a full-body motion capture system that integrates directly into your pipeline. It enables you to mocap anywhere and everywhere, in any situation.

By adding the Xsens Metagloves by Manus, you can have full-body performance capture including finger tracking.

If you have any questions about the integration of Xsens Metagloves by Manus with Xsens motion capture, feel free to reach out to us.

Xsens Metagloves by Manus 217

Downloads & Documentation
